Project |
CNC38 |
CNC50 |
CNC63 |
CNC75 |
|
|
Maximum pipe diameter （Pipe diameterXWall thickness） |
iron pipe |
φ38.1x2.Ot |
φ50.8x2.5t |
φ63.5x3.0t |
φ75x3.5t |
|
stainless steel pipe |
φ32x1,8t |
φ45x2.0t |
φ50.8x2.0t |
φ65x2.5t |
|
|
Corner tube |
φ32x1.8t |
φ45x2.0t |
φ5Ox2.5t |
φ63x3.0t |
|
|
Maximum bending radius |
150mm |
200mm |
250mm |
350mm |
|
|
Maximum bending angle |
200° |
200° |
200° |
190° |
|
|
Maximum effective through-core distance |
2000mm |
2500mm |
3000mm |
3500mm |
|
|
Bending shaft |
Precision |
±0.05 |
±0.05 |
±0.05 |
±0.05 |
|
speed（s） |
150° |
110° |
100° |
65° |
|
|
Infeed shaft |
Precision |
±0.05 |
±0.05 |
±0.05 |
±0.05 |
|
speed（s） |
1100mm |
1000mm |
1000mm |
750mm |
|
|
Rotational axis |
Precision |
±0.05 |
±0.05 |
±0.05 |
±0.05 |
|
speed（s） |
240° |
200° |
200° |
180° |
|
|
Maximum distance between two layers R |
50 |
60 |
65 |
70 |
|
|
Size（LxWxH） |
4200x1500x1700mm |
5100x1600x1700mm |
6000x1700x1700mm |
6300x2150x1700mm |
|
|
Weight |
2200kg |
4500kg |
5500kg |
8000kg |
|
